7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
166 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
7.2.9.4 M22-SWD-LED(C)-RGB
The function element features five data profiles that are used to define the
scope of the corresponding cyclical data.
1. Profile 1 - Compact Solution
One color out of five preset colors can be selected with an index.
2. Profile 2 - Index
There are 7 fixed preset colors. In addition, 16 colors can be defined at
runtime in a color table with SWD-Assist. The colors can be selected with
an index.
3. Profile 3 - RGB16
65,535 colors can be defined in one word.
4. Profile 4 - RGB24
For showing 24-bit color with an LED. There is one byte available for the
red, green, and blue color components each. This means that 16,777,216
colors can be defined. The color information will be transmitted at run-
time with cyclical services.
5. Profile 5- Index+RGB24
Provides the option of either selecting the color from the color table with
an index as in profile 2 or of defining the color components with three
bytes (as in profile 4). The color information will be transmitted at runtime
with cyclical services.
All profiles allow for the LED to flash. Moreover, profiles 2 to 5 allow dim-
ming.
Profile Number of input bytes Number of output bytes
1 1 1
2
1 2
3
2 3
4
1 4
5
1 5
