7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 167
Input points
The input byte is the same for all profiles.
Byte 0:
Profile 1 – Compact solution
1 input byte, 1 output byte
The index can be used to select a color from five fixed, defined colors in the
color table. In addition, flashing mode can be selected for red and green. For
more information, please refer to the color table ￫ Section “13.4.1 Color
table profile 1”, page 257.
Outputs
Byte 0:
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
76543210
Index
Index Color (RGB) Flashing ?Frequency
0 LED off - -
1
Red (200, 0, 0) - -
2
Green (0, 200, 0) - -
3
Yellow (100, 100, 0) - -
4
Blue (0, 0, 200) - -
5
Green (0, 200, 0) 50/50 % 1 Hz
6
White (70, 70, 70) - -
7
Red (200, 0, 0) 50/50 % 1 Hz
