7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 173
Table 44: Flashing mark-to-space ratio settings
Byte 1:
Color selection with red component of 0 to 255 in RGB color space.
Byte 2:
Color selection with green component of 0 to 255 in RGB color space.
Byte 3:
Color selection with blue component of 0 to 255 in RGB color space.
Bit 2 Bit 1 Mark-to-space ratio as a
percentage of the total signal
0 0 No flashing
0 1 50 / 50
1 0 25 / 75
1 1 75 / 25
76543210
Red color component
76543210
Green color component
76543210
Blue color component
