7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
174 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Profile 5 – Index+RGB24
1 input byte, 5 output bytes
The 24-bit color can be optionally selected with bytes 2 to 4 or with the index
in byte 1.
Outputs
Byte 0:
The LED is switched on and off with bit 0.
By changing the content of bits 5 to 7, the brightness can be reduced to any
of seven settings.
Table 45: Brightness setting
By changing the content of bits 3 to 4, the LED's flashing frequency can be
defined. If both bits have a state of "0", the LED will not flash even if a mark-
to-space ratio has been set.
Table 46: Flashing frequency settings
By changing the content of bits 1 to 2, the mark-to-space ratio for LED flash-
ing can be defined. If both bits have a state of "0", there will be no flashing
even if a flashing frequency has been set.
76543210
Brightness ?Frequency Flashing LED
on/off
Bit 7 Bit 6 Bit 5
0 0 0 Full brightness
0 0 1 First dimming setting
---…
1 1 1 Seventh dimming setting
￫
Please note that when using mixed colors, there may be color
deviations in the last two dimming settings.
Bit 4 Bit 3
0 0 No flashing
01 1 Hz
1 0 0.5 Hz
11 2 Hz
