7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
188 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
For additional information, please refer to "Fieldbus-specific characteristics" in
the "Parameter configuration" section for each individual module.
4, 5 Scroll speed Bit 4 Bit 5
0 0 = Increase every detent
0 1 = Increase every 2 detents
1 0 Increase every 4 detents
1 1 = Increase every 8 detents
6
Reset with pushbutton 0 = Off
1 = On
7
Suppress 0x2E diagnostics 0 = "Pushbutton fault" (0x2E) will be signaled
1 = "Pushbutton fault" (0x2E) will not be signaled
Bit
Function Configuration
Bold values indicate the default settings.
