Eaton SmartWire-DT SWD Series User Manual

7 Pilot devices M22-SWD…
7.3 M22-SWD base fixing
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 193
Table 53: Configuration in the M22-I… enclosure
Function element
M22-I… enclosure configuration
(base fixing - viewed from the front while equip-
ping the enclosure)
Location on the PCB
(marking on the enclosure base)
2 3 1
M22-SWD-KC11
O X
1)
O
2)
M22-SWD-LEDC O X O
M22-SWD-K11LEDC
O X O
M22-SWD-KC22
X X O
M22-SWD-K22LEDC
X X O
M22-SWD-SEL-8-10
O X O
1) X = occupied by SWD element
2) O = optional for an additional M22-KC10/KC01 element
￫
The function elements obtain the energy for communication
electronics and driving the LEDs from the SmartWire-DT net-
work supply.
So please take into consideration the total power consumption
of your SmartWire-DT network; if necessary, plan for an addi-
tional feeder module EU5E-SWD-PF2-1.
You will find information on the current consumption in the
appendix on Page 253.
For questions about current consumption the software program
SWD-Assist also supports you in doing this by automatically per-
forming these calculations.
http://www.eaton.eu/software
