Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.8 Programming
240 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
All other
17
0 t
r
=2 Set value for t
r
[s]
17
1 t
r
=4
17 2 t
r
=6
17 3 t
r
=8
17 4 t
r
=10
17 5 t
r
=14
17 6 t
r
=17
17 7 t
r
=20
17 8 t
r
=infinite
• NZM3-VE-630, -VE-250…400-NA, , -VEF-250…400-NA,
-VE-450…600-NA, -VEF-450…600-NA
18
0 I
sd
=1.5xI
r
Set value for I
sd
18 1 I
sd
=2xI
r
18 2 I
sd
=2.5xI
r
18 3 I
sd
=3xI
r
18 4 I
sd
=3.5xI
r
18 5 I
sd
=4xI
r
18 6 I
sd
=5xI
r
18 7 I
sd
=6xI
r
18 8 I
sd
=7xI
r
• NZM4-VE2000
18
0 I
sd
=2xI
r
Set value for I
sd
18 1 I
sd
=2.5xI
r
18 2 I
sd
=3xI
r
18 3 I
sd
=3.5xI
r
18 4 I
sd
=4xI
r
18 5 I
sd
=4.5xI
r
18 6 I
sd
=5xI
r
18 7 I
sd
=5.5xI
r
18 8 I
sd
=6xI
r
Byte Dec.
value
Description Remark
