Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.8 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 239
• NZM2-ME, -SE…-NA
• NZM3-ME-220, -350, -450, -SE-220, -SE-350, -SE-450-NA
• NZM4-ME, -SE…-NA
16
0 I
i
=2xI
r
Set value for I
i
16 1 I
i
=3xI
r
16 2 I
i
=4xI
r
16 3 I
i
=5xI
r
16 4 I
i
=6xI
r
16 5 I
i
=8xI
r
16 6 I
i
=10xI
r
16 7 I
i
=12xI
r
16 8 I
i
=14xI
r
• NZMX-VEF…-NA, -VE…-NA
• NZM2-ME…-NA
17
0 t
r
=2 Set value for t
r
[s]
17
1 t
r
=4
17 2 t
r
=6
17 3 t
r
=8
17 4 t
r
=10
17 5 t
r
=12
17 6 t
r
=14
17 7 t
r
=17
17 8 t
r
=20
• NZM3-4-VE630
17
0 t
r
=2 Set value for t
r
[s]
17
1 t
r
=4
17 2 t
r
=6
17 3 t
r
=8
17 4 t
r
=10
17 5 t
r
=14
17 6 t
r
=infinite
17 7 t
r
=2
17 8 t
r
=2
Byte Dec.
value
Description Remark
