Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.8 Programming
238 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
15 6 I
r
=0.8xI
n
15 7 I
r
=0.85xI
n
15 8 I
r
=0.9xI
n
15 9 I
r
= 0.925 x I
n
15 10 I
r
=0.95xI
n
15 11 I
r
= 0.975 x I
n
15 12 I
r
=1.0xI
n
• NZM2-AE, -AEF-NA, -VE, -VE-NA, -VEF-NA
• NZM4-AE, -AE-NA, -AEF-NA, -VE, -VE-NA, -VEF-NA
16
0 I
i
=2xI
n
Set value for I
i
16 1 I
i
=3xI
n
16 2 I
i
=4xI
n
16 3 I
i
=5xI
n
16 4 I
i
=6xI
n
16 5 I
i
=7xI
n
16 6 I
i
=8xI
n
16 7 I
i
=10xI
n
16 8 I
i
=12xI
n
• NZM3-AE-250, -AE-400, -AE-250, -AE-400-NA,
-AEF-250…400-NA, -VE-250, -VE-400, -VE-250, -VE-400-NA,
-VEF-250…400-NA
16
0 I
i
=2xI
n
Set value for I
i
16 1 I
i
=3xI
n
16 2 I
i
=4xI
n
16 3 I
i
=5xI
n
16 4 I
i
=6xI
n
16 5 I
i
=7xI
n
16 6 I
i
=8xI
n
16 7 I
i
=9xI
n
16 8 I
i
=11xI
n
• NZM3-AE-630, -AE-630-NA, -AEF-450…550-NA,
-AEF-600-NA, VE-630, -VE-600-NA, -VEF-450…550-NA,
-VEF-600-NA
16
0 I
i
=2xI
n
Set value for I
i
16 1 I
i
=2.5xI
n
16 2 I
i
=3xI
n
16 3 I
i
=3.5xI
n
16 4 I
i
=4xI
n
16 5 I
i
=5xI
n
16 6 I
i
=6xI
n
16 7 I
i
=7xI
n
16 8 I
i
=8xI
n
Byte Dec.
value
Description Remark
