Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.8 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 237
11.8.1.4 Currents: profile 2
Profile 2 contains the digital status data as well as the phase currents that
the table shows.
1)
• With a Motorola-based GSD (Moel4d14.gsd), the currents are stated in the order High byte, Low byte,
• With an Intel-based GSD (Moe4d14.gsd) the currents are stated as word values.
• Current values are measured from I > 0.2 × I
n
. At smaller currents the value is zero.
11.8.1.5 Energy values: profile 3
In addition to the data of profile 2, profile 3 contains the energy values
shown in the table.
11.8.1.6 Actual parameters and circuit-breaker data: profile 4
Profile 4 contains the digital status data, the phase currents, the energy val-
ues as well as the circuit-breaker data with the currently set values.
Byte Bit Description Remark
7 6 5 4 3 2 1 0
3 X X X X X X X X Current I1 [A]
1)
RMS value
4 X X X X X X X X Current I1 [A]
1)
5 X X X X X X X X Current I2 [A]
1)
6 X X X X X X X X Current I2 [A]
1)
7 X X X X X X X X Current I3 [A]
1)
8 X X X X X X X X Current I3 [A]
1)
9 X X X X X X X X Current I
max
[A]
1)
Maximum value of the three phase
currents
10
X X X X X X X X Current I
max
[A]
1)
Byte Bit Description Remark
7 6 5 4 3 2 1 0
11 X X X X X X X X Energy value high section S0 counter value 32 bit
12 X X X X X X X X Energy value high section S0 counter value 32 bit
13 X X X X X X X X Energy value low section S0 counter value 32 bit
14 X X X X X X X X Energy value low section S0 counter value 32 bit
Byte Dec.
value
Description Remark
15 0 I
r
=0.5xI
n
Set value for I
r
15 1 I
r
=0.55xI
n
15 2 I
r
=0.6xI
n
15 3 I
r
=0.65xI
n
15 4 I
r
=0.7xI
n
15 5 I
r
=0.75xI
n
