Eaton SmartWire-DT SWD Series User Manual

11 Interface for NZM compact circuit-breakers
11.8 Programming
236 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
11.8.1.3 Digital status data: profile 1
1) The last cause of tripping registered is always indicated. The circuit-breaker is reset by switching it on, or by switching the
power supply off/on. It may take up to 30 s before the trip reason is displayed.
After a trip, the last current values measured are displayed (rms values).
Object 2102subx
(x represents the position of the NZM
module in the SWD line)
Contents
Profile 1 0xA292
Profile 2 (default)
0xA2D392
Profile 3
0xA2D592
Profile 4
A29FD592
Byte Bit Description Remark
7 6 5 4 3 2 1 0
0 X 1 = internal fault in NZM-XSWD-
704
–
0 X 1 = Short-circuit output Q0 or Q1 –
0 X 1 = Power meters invalid Fault found in FRAM
0 X 1 = Overload warning 2 > 120 % I > 120 % I
r
0 X 1 = Group diagnostics from XSWD-704
0 X 1 = module present
0 = module not present
P or PRSNT
1
X X LS position:
• 01 = LS connected
• 11 = No CB connected
–
1
X X LS status:
• 00 = Init
• 01 = Off
• 10 = On
• 11 = Trip
–
1
X Availability Identical to “Off” position
1
X 1 = Overload warning 1 > 100 % I > 100 % I
r
2 X Group warning Load warning or overload warning
1 or overload warning 2
2
X X X
000 = OK
001 = Trip I
r
010 = Trip I
i
011 = Trip I
sd
100 = Trip I
g
101 = TripTemp or Trip Err
110 = Trip I
r
in neutral conductor
Cause of trip1
)
No trip
Long-time trip
Instantaneous trip
Short-time trip
Ground fault trip
Extended protection
Overcurrent neutral conductor
2
X 1 = Load warning > 70% I > 70 % I
r
