Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
266 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
10 V
Ambient climatic conditions
Operating ambient temperature
(IEC 60068-2)
-25 - +55 °C
Condensation
Must be prevented with suitable measures
Storage
-40 - +70°C
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
5 - 95 %
SmartWire-DT interface
Module type SmartWire-DT module (slave)
Baud rate setting
Automatic Automatic Automatic Automatic Automatic
Status SmartWire-DT LED
Green Green Green Green Green
Device supply voltage
SWD module U
SWD
14.5V DC (±3 %)
Current consumption at U
SWD
￫ Page 253
Connection
Pin contact strip, 8-pin; Connector: External device plug SWD4-8SF2-5
Connection supply and I/O
Connection type Push-In Push-In Push-In Push-In Push-In
solid
mm2
0.25 - 1.5 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5
flexible with ferrule
1) mm2
0.25 - 1.5 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5 0.25 - 1.5
UL/CSA solid or
stranded
AWG
24 - 16 24 - 16 24 - 16 24 - 16 24 - 16
24 V DC supply for output
supply
Rated operating
voltage
U
e
– 24 V DC
-15 % / +20 %
– 24 V DC
-15 % / +20 %
24 V DC
-15 % / +20 %
Residual ripple of input voltage
– ≦ 5% ≦ 5% ≦ 5%
Protection against polarity reversal
no Yes no Yes Yes
Digital inputs
Qty. 8 4 (three-wire
connection with
supply I+, I-)
4 4
Input current mA normally 4 at 24 V
DC
normally 4 at 24 V
DC
normally 4 at 24 V
DC
normally 4 at 24 V
DC
–
Voltage level to IEC/EN 61131-2
Limit value type 1 Low < 5 V DC; High > 15 V DC
Input delay High Low typ. < 0.2 ms
Low High typ. < 0.2 ms
Status display inputs LED yellow yellow yellow yellow yellow
Input supply I+, I-
Specifications for
connection to supply
voltage
V U
e
- 0.16 V
Output current per
input supply
A ≦ 0.5
EU5E-SWD-8DX EU5E-SWD-4DX EU5E-SWD-4D2R EU5E-SWD-4D4D/
EU5E-...-4D4D-R
EU5E-X8D
