Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 267
Overload proof yes, with diagnos-
tics
Status display inputs LED yellow yellow yellow yellow
Digital semiconductor outputs
Qty. – 4 8
Output current A
– normally 0.5 at
24 V DC
normally 0.5 at
24 V DC
Short-circuit detection
threshold
A
– max. 1.2 over 3 ms max. 1.2 over 3 ms
lamp load R
LL
– ≦ 3W ≦ 3W
Overload proof
– yes, with diagnos-
tics
yes, with diagnos-
tics
Switching capacity
– EN 60947-5-1 utili-
zation category DC-
13
EN 60947-5-1 utili-
zation category DC-
13
Relay outputs
Qty. – – 2 – –
Contact type
– – Make – –
c (contacts)
Utilization category AC-1, 250
V, 4 A
– – > 5 x 10
4
– –
Utilization category AC-15, 250
V, 3 A
– – > 5 x 10
4
– –
Utilization category DC-13, 24
V, 1 A
– – > 2 x 10
5
– –
Safe disconnection V AC
– – 230 – –
minimum load current mA
– – 100 mA , 12 V DC – –
Response/reset time ms
– – 5/2.5 – –
Bounce duration ms
– – Normally 1.5 – –
Short circuit protection
– – external 4 A gL/gG – –
Status display outputs LED
– – yellow yellow yellow
Potential isolation
Input to SmartWire-DT Yes Yes Yes Yes –
Output to SmartWire-DT
– no Yes Yes Yes
Input to input
no no no no –
Output to input
– no Yes no –
Output to output
– no Yes no no
Notes 1) Minimum length 8 mm
EU5E-SWD-8DX EU5E-SWD-4DX EU5E-SWD-4D2R EU5E-SWD-4D4D/
EU5E-...-4D4D-R
