Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.9 Digital module EU5E-SWD-4D4D-R
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 41
This ensures that undesired changes will not occur at the outputs when the
controller is started.
Output configured as non-retentive (default setting):
Driving will be based on simple output setting and resetting.
2.9.7.3 Diagnostics
In case of diagnosis, the module reports the following fault cause (bit 4 in
input byte 0 is set):
76543210
––––Q3Q2Q1Q0
Bit
Designation Meaning
Output configured as retentive
Meaning
Output configured as non-retentive
Bit 1 Bit 0 Bit 1
0 Q0R 0 0 No Change
0 1 Output OFF
1 Q0S 1 0 Output ON 1 Output ON
1 1 No Change 0 Output OFF
Bit 3 Bit 2 Bit 3
2 Q1R 0 0 No Change
0 1 Output OFF
3 Q1S 1 0 Output ON 1 Output ON
1 1 No Change 0 Output OFF
Bit 5 Bit 4 Bit 5
4 Q2R 0 0 No Change
0 1 Output OFF
5 Q2S 1 0 Output ON 1 Output ON
1 1 No Change 0 Output OFF
Bit 7 Bit 6 Bit 7
6 Q3R 0 0 No Change
0 1 Output OFF
7 Q3S 1 0 Output ON 1 Output ON
1 1 No Change 0 Output OFF
Value Description
0x13 Short-circuit/overload on at least one output
