Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.10 Digital module EU5E-SWD-4D2R
44 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Byte 1:
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: universal module M22-SWD-
NOP(C) present
76543210
––––I3I2I1I0
Bit
Designation Description
0 I0 Status input I0
1
I1 Status input I1
2
I2 Status input I2
3
I3 Status input I3
4
Not used –
5
Not used –
6
Not used –
7
Not used –
