2 I/O modules EU5E-SWD…
2.10 Digital module EU5E-SWD-4D2R
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 45
2.10.7.2 Outputs
Byte 0:
2.10.7.3 Diagnostics
The module does not report a diagnosis.
76543210
––––––Q1Q0
Bit
Designation Description
0 Q0 Actuation output Q0
1
Q1 Actuation output Q1
2
Not used –
3
Not used –
4
Not used –
5
Not used –
6
Not used –
7
Not used –
