WaveRIDER 167
COUPON TEMPERATURE STATISTICS
For all three coupon T/C’s, the following is recorded:
(exception: solder sensor slopes are not calculated since they are normally very fast).
Min: Lowest temperature seen throughout the data set.
Max: Highest temperature seen throughout the data set.
Max (-) Slope
: Greatest negative (falling) temperature change seen throughout the data
set.
Max (+) Slope
: Greatest positive (rising) temperature change seen throughout the data
set.
Slope is measured over a 1 second time interval using a “linear regression”
technique (m = Slope).
Time > 361F (183C) = The total time spent above the typical solder melting point.
