170 WaveRIDER
Statistics tab
Values shown in this tab are taken from the graph at it’s present level of magnification.
X-axis values outside of view are not included in the calculations. Y-axis values,
however are included regardless of magnification level.
Minimum is the lowest value measured. The values below are the minimum values for
each channel.
Minimum X is the point in time where the minimum value occurred. The values below
are the first point on the X-axis where the minimum value occurred for each channel.
Maximum is the highest value measured. The values below are the maximum values
for each channel.
Maximum X is the point in time where the maximum value occurred. The values below
are the first point on the X-axis where the maximum value occurred for each channel.
Average is based on the following equation:
Where n is the number of data points and x is the value of any given data point. The
values below are the average values for each channel.
Standard Deviation is based on the following equation:
Where n is the number of data points and x is the value of any given data point. The
values below are the standard deviation values for each channel. Small standard
deviation means the data is used to calculate it is well centered around the average of
that same data.
(
n x
2
(
x
)
2
)
/n
x/n
