WaveRIDER 171
Summary Statistics tab
Values shown in this tab are taken from the intire graph regardless of its level of
magnification.
Peak Temperature is the largest measured value. Values below are the largest value
recorded for that channel. The higher the peak temperature, the greater the possibility
for component damage.
Figure D- 1: Peak Temp
PEAK TEMP
