WaveRIDER 179
KPI tab
Values shown in this tab are set by the user.
● Temperature Parameters:
Peak Temperature is the largest measured value. Values below are the largest value
recorded for that channel. The higher the peak temperature, the greater the possibility
for component damage.
Min Temperature is the smallest measured value. Values below are the smallest value
recorded for that channel. Typically, these are the starting values, unless there is active
cooling employed. It is best if starting temperature values are close to the same. This
will allow a consistent starting point for other measurements.
Max Slope (+) is the largest slope measured using the seconds specified in the user
configured calculate slope value text box. This column then displays slopes in the
positive direction.
Max Slope (-) is the largest slope measured using the seconds specified in the user
configured calculate slope value text box. This column then displays slopes in the
negative direction.
Max Slope (+ or -) is the largest slope measured using the seconds specified in the
user configured calculate slope value text box. This column then displays the larges
slope in the positive or negative direction depending on which is larger.
● X Cursor Parameter Data:
C1, C2, C3, C4 indicate the point, time relative, time absolute, or distance (depending
on the Units setting) on the X axis where the vertical cursors are set, respectively. The
values below are the measured values for each channel at that position.
Slope between Cursor locations is the straight line slope between any two cursors.
