WaveRIDER 19

6) Place the RIDER on to the Wave solder machine conveyor. Make sure the

RIDER is being fed into the machine in the proper direction. There are two

arrows on the RIDER barrier that indicates the proper direction. If a manual feed

wave solder machine is being used, hold the RIDER until the conveyor fingers

have completely grabbed the RIDER.

Figure 3- 2: Proper RIDER Loading

CONVEYOR

DIRECTION

RROW
