WaveRIDER 21
Data Collection Tips:
When turning the WaveRIDER “OFF” after the data collection process is
complete, do not release the button until the light goes off. Pressing the
Start/Stop button briefly will restart the data collection process and erase all the
data in memory.
The WaveRIDER continues to capture data until its memory is full or until it is
turned “OFF". It is recommended to turn RIDER “ON” after it is placed on the
wave solder machine conveyor, then turn it “OFF” as soon as possible after it
exits the solder machine.
If the production process uses pallets, the WaveRIDER sensors may not come in
contact with the solder wave. If this condition occurs, try the following options:
a) Install the RIDER into one of the pallets, which can adjust to fit the RIDER.
b) Raise the solder wave(s) height. (This does not represent actual machine use so
this option should be avoided).
