44 WaveRIDER
2) Select a data filter by:
Clicking the greater than relational operator option button beside the left data
column.
Click a parameter value from the list or type it in the text box.
Click the AND logical operator option button.
Click the less than relational operator option button beside the right data column.
Click a parameter value from the list or type it in the text box.
The Clear command button can be selected at any time to clear the selections and
the new values can be selected.
3) Click the OK command button to accept the selected data filters or Cancel to
return to the worksheet without executing the filter request.
Figure 4- 16: Special Filter Feature Dialog Box
In this example, the data filtered would be all times between, but not including 06:25:33
and 14:08:00.
To reset all of the data set rows to restore the entire set of collected data, click
the Filter Reset button on the Spreadsheet worksheet.
