74 WaveRIDER
4.4.10.6 X-axis Units
The user can select three different types of X scales for the X-axis. The scales are
Point, Time (time measure from process origin), and Distance. To change, select the X-
axis Units command in the Profile menu.
The scale is displayed only when a data tab other than Value is selected.
Figure 4- 40: Scale Types
DISTANCE
SCALE
TIME
LOGGED
POINT
SCALE
