ECD WaveRIDER Series User Manual

WaveRIDER 75
4.4.10.7 Temperature Reference Lines
Temperature Reference Lines are colored horizontal lines that are positioned within the
range of Y-values in the graph. Up to three Temperature reference lines can be added
to the Data Graph using the Temp Ref Lines command in the Profile menu.
Figure 4- 41: Temp Ref Lines
Temperature Reference Lines are used in analysis when the T Above Ref (Time above
the Reference Line) statistic is active. (T Above Ref statistic is described in section
4.4.9.3 T Above Ref).
TEMP REF
LINE
