Hysteresis a) For the Polarity=Above parameter
If the value of the Source channel is greater than the predefined Upper value
threshold, the value of the operation will be 1. If it is lower than the Lower value
threshold, the value of the operation will be 0. If it falls between [Lower value, Upper
value] the value of the operation will be the previous value.
b) For the Polarity=Below parameter
If the value of the Source channel is lower than the predefined Lower value threshold,
the value of the operation will be 1. If it is greater than the Upper value threshold, the
value of the operation will be 0. If it falls between [Lower value, Upper value] the
value of the operation will be the previous value.
IMPORTANT!
For the Pulse, Flash and Changed operations, setting the Time on parameter to 0s will
result in generation of an impulse of 2ms.
