Tire temperature gradient
The Tire temperature gradient displays the temperature gradient and the temperature values
assigned to a given colour. Configuration of the measurement range of the cameras is in the
ADU/Configuration/Tire temperature cameras panel.
Parameter Description
Position X,Y Object position on the page The reference point is the upper-left corner
of a rectangle around the object.
Scale Defines the gradient size
Legend color Defines the description colour
Page 70/137
Object description
Tire temperature
gradient
Temp. gradient
Legend
