Text
This indicator allows you to display text with data from a log channel or function, along with a
measurement unit. The user can also hide the object using a function or a log channel.
Parameter Description
Position X,Y Object position on the page The reference point is the upper-left corner
of a rectangle around the object.
Channel Name of a channel or a variable that will be displayed in the Value field
and that will be represented on the gauge. Here you can also enter a
numerical value without a decimal separator to test the operation of the
gauge.
Color Displayed text colour
Font Displayed font size
Italic Activates the italic mode
Two lines Displays channel value in separate line
Second line font Font size for secont text line
Text A field containing the displayed text
Text width The area width used by the Text align functions. For example, by
entering 800 (screen width), setting the position X as 0 and selecting
appropriate alignment, you can display the text to the left side of the
screen, in the centre of the screen and to the right side of the screen.
Text align Defines text alignment in the Text width area.
Left – aligning the text to the left
Center – center alignment,
Right – aligning the text to the right
Channel Name of a channel or a variable that will be displayed in the Value field
and that will be represented on the gauge. Here you can also enter a
numerical value without a decimal separator to test the operation of the
