Panels
Panels contain additional device configurations not included in the main menu and the Project
tree.
Buttons
The Buttons panel allows you to assign buttons to different internal functions of the device, such
as switching between pages, cancelling alarms, resetting times for a given track, etc.
A given function (e.g. next page) is configured by selecting a channel/function representing a
button and the button interpretation method (trigger).
There are 4 channel interpretation types (trigger):
Press - a function is activated by pressing a button
Release - a function is activated by releasing a button
Click - a function is activated by quickly pressing and releasing a button
Hold - a function is activated by pressing and holding a button
Position Description
Next page Switching to the next page
Previous page Switching to the previous page
Acknowledge alarm#1 Cancelling the alarm displayed on the screen
Acknowledge alarm#2 Cancelling the alarm displayed on the screen
Reset session Cancelling the internal Session time clock
Reset distance meter Cancelling the distance meter (the adu.distanceMeter channel)
Reset track data Cancelling the list of the best times and the reference lap for the current
racing track
Beacon input A channel access from an external beacon. It informs the ADU about
completion of another lap
Page 122/137
