User lights
The User lights functions allow to control the LEDs on both sides of the device. This way they can
be assigned their own functions (e.g. Indicators, alarms).
Parameter Description
Master brightness The LED brightness scale. Each LED can be a assigned a brightness
ranging from 0-100%. The Master brightness parameter influences the
brightness of all LEDs.
Led 1 function Selection of a function for LED no. 1.
User LED1 – LED no. 1 behaves like the other LEDs and can be assigned a
user function
USB logger state still – LED no. 1 displays the state of logging into the
memory connected to the USB port.
USB logger state flashing - LED no. 1 displays the state of logging into
the memory connected to the USB port.
Type We can select the control method for each LED:
On/Off – the simplest control where an LED assumes two states: off (if the
value of the variable assigned in the Channel field equals 0) or on (if the
value of the variable in the Channel field differs from 0). If a LED is on, its
colour is defined as Color 1
Choose – an LED assumes two states whose colour is defined in the Color
1 and Color 2 fields. The state depends on the value of the variable in the
Channel field.
Choose + override – an LED can assume three states whose colour is
defined in the Color 1, Color 2 and Color 3 fields. The two first states are
controlled the same way as in the Choose type. The third state is
controlled by means of a variable assigned to the Channel 3 field. When
this variable assumes a value different from zero, the LED colour will
change to the value from the Color 3 fields irrespective of the value of the
variable in the Channel field
Channel A variable defining the state of a given LED.
Page 86/137
