Ecumaster ADU-5 User Manual

Predictive time graph
The Predictive time graph object indicates the time difference between the best reference lap and
the current position on the track. This object requires a GPS module and a correct configuration of
the racing track.
Parameter Description
Position X,Y Object position on the page The reference point is the upper-left corner
of a rectangle around the object.
Width Object width
Height Object height
Gain color The colour of the graph when the current time is faster than the reference
time
Loss color The colour of the graph when the current time is slower than the
reference time
Lines color The graph line colour
Font size The font size
Page 68/137
Loss
Object
description
Predictive
time graph
Gain
Legend
