Ecumaster ADU-5 - Device Description

Device description
Front view
Position Description
Connection status LED indicating communication with PC. Flashes green when online
Light sensor Light sensor is used for automatic control of the display and light-emitting
diodes' brightness
User led #1- #6 RGB LEDs that can be controlled by user functions (e.g. Alarms,
indicators, etc.)
Shift light Gear change indicator (user configurable)
Page 8/137
