Pages
Pages represent what will be displayed on the ADU screen. The ADU software allows you to
create multiple pages (the number allowed depends on their complexity and memory usage).
You can switch between pages by means of an external button or a function (e.g. a different page
is displayed when the car is stationary than when it is moving).
There are 3 types of pages:
– Page – a standard page
– Overlay – a page which can be overlaid on another page.
– Overlay with background – a page similar to the Overlay page, but with a non-
transparent background
Additionally, an alert or warning can be displayed regardless of the current page (more information
in the Alerts chapter).
Creating a page
To create a page click Add in Project tree and select Page. A pg_1 (1) page should appear in the
project.
The currently selected page with its elements and configuration will appear in Page editor (2). At
this point we don’t have any elements defined for the page shown, but we can set the following
page attributes:
