Permanent meters
The ADU contains 4 permanent meters. That is, meters whose value is stored in memory even
after switching the device off.
Meter name Channel Description
Odometer adu.odometer An odometer, a travel distance meter
Distance meter adu.distanceMeter An additional, resettable odometer. It can be reset by
means of a button defined in the Buttons panel: Reset
distance meter - channel / trigger
Engine hour meter adu.engineHours It measures the number of hours the engine has run.
(ecu.rpm > 0 channel)
Hours at load
meter
adu.hoursAtLoad It measures the number of hours the engine has run
under load. The parameters that define load can be
configured in the Configuration/Hours at load meter:
• Minimal ecu.rpm
• Minimal ecu.tps
• Minimal ecu.map
A screen containing meters with example values.
Page 119/137
