Ecumaster ADU-5 - Device Characteristics

Characteristics
General
Working temperature range ACEQ100 (-40 – 85 C)
CPU 32 bits, automotive, 90 MIPS
Reverse polarity protection Yes, internal
Working voltage range 6-22V, robust supply protection compliant to ISO 7637
Housing Anodized aluminium, CNC-machined
IP code IP 60
Connector 1 x 35 position, AMP automotive
Communication with PC CAN bus Ecumaster interface, Peak or Kvaser
Display type TFT 800x600
Brightness of display 5” - 600 cd/m
2
, 7” - 1000 cd/m
2
Inputs / Outputs
Analogue inputs 8 inputs, 10 bits, 0-5 V, software controlled pull-up/pull-down
10K resistor. Al analog inputs can be used as a switches
Digital inputs 8 digital inputs, software controlled input sensitivity (VR, Hall),
software controlled 4K7 pull-up resistors, used for engine speed
sensors, Flex Fuel, wheel speeds, turbocharger shaft speed. All
digital inputs can be used as a switches
Outputs 2 low side outputs (switch to ground), up to 2A
+ 5V output Monitored 5V output for powering external sensors
Communication
CAN Interface 2 x CAN2.0 A/B, 250, 500, 1000 Kbps
CAN streams User-defined
Serial communication RS232 Rx/Tx, AiM protocols, Ecumaster, Hondata Kpro,
Autronic
USB Used for logging to external USB memory
Others
Light Emitting Diodes 15 ultra bright RGB LEDs
Accelerometer/gyroscope 3D accelerometer + 3D gyroscope for the analysis of vehicle
dynamics
Real-time clock Yes, battery powered
Light sensor Yes, for automatic correction of brightness
Temperature sensor Yes, for monitoring device temperature
