Ecumaster ADU
ECUMASTER ADU (Advanced Display Unit) is a universal display designed for motorsports. Unlike
similar devices on the market, the Ecumaster ADU offers a high degree of configurability of the
displayed information and remarkable flexibility for configuring inputs. Equipped with two CAN
buses, the display can easily communicate with other devices (e.g. ECU, GPS, ABS, etc.).
Additionally, up to 8 analogue inputs (e.g. pressure sensors, temperature sensors) and 8 digital
inputs (signals from frequency sensors, beacon etc.) may be connected and configured.
A secondary method of relaying information to the driver is a set of 15 RGB LEDs. These LEDs are
useful for relaying warnings (such as low oil pressure) and as a progressive shift light.
To ensure user comfort in various lighting conditions, a high-quality LCD display was chosen, with
a brightness of 600 cd/m2 for the ADU5 display and 1000 cd/m2 for the ADU7 display. In order to
reduce reflections, the display features an anti-glare coating. The front of the enclosure features
a light sensor that automatically adjusts the brightness of the display to suit current conditions.
The ADU may also be used as a central data logger. All information collected by the display can be
saved on an USB storage device (flash drive, pen drive) recorded at up to 500 Hz per channel. The
ADU features a real-time clock, so all data is stored with the date and time of the recording.
The ADU is a powerful tool for lap timing and driver training. Lap and sector times may be recorded
using an external GPS module, and the driver may be coached in real time using predictive lap
timing. Timing information may be reviewed from logged data after the fact and analyzed.
