Windows software
Configuring the display requires the Windows based software available at www.ecumaster.com.
Hardware requirements to run the software:
– Windows XP, VISTA, 7, 8 and 10 (32 or 64 bit)
– Minimum screen resolution of 1366x768
– Open GL-supporting graphics card
– 2GB RAM
– A USB port
After installing and opening the software, you should see the following screen:
The primary window is the Project tree (1) pane. Use this pane to define all project items. Click
Add to add a new item.
You may choose from:
– Analog input – an analog input, where parameters can be defined, such as the input
channel, the name of the variable, the type (temperature, pressure), pullup etc.
– Digital input – a digital input whose properties can be defined, such as type, sensitivity,
variable name, pullup, etc.
Page 26/137
