12. Battery 12V Power supply and backup for the real-time clock when the device is turned
off (when no +12V signal at terminal 11). In the case that there is no 12V
battery power, the real-time clock is powered by an internal battery.
13. USB.DM D- signal to the USB port
14. USB.DP D+ signal to the USB port
15. Analog in 5 Analogue input 5. Measuring range 0-5V
16. Analog in 3 Analogue input 3. Measuring range 0-5V
17. Analog in 1 Analogue input 3. Measuring range 0-5V
18. Digital in 8 Digital input 8
19. Digital in 6 Digital input 6
20. Digital in 4 Digital input 4
21. Digital in 2 Digital input 2. The only input that can be used by a Flex fuel sensor
22. Power ground Device ground used by the AUX outputs and LEDs
23. Ground Device ground
24. Analog in 8 Analogue input 8. Measuring range 0-5V
25. Analog in 7 Analogue input 7. Measuring range 0-5V
26. Analog in 6 Analogue input 6. Measuring range 0-5V
27. Analog in 4 Analogue input 4. Measuring range 0-5V
28. Analog in 2 Analogue input 2. Measuring range 0-5V
29. Analog out Analogue output 0-5V
30. Digital in 7 Digital input 7
31. Digital in 5 Digital input 5
32. Digital in 3 Digital input 3 .This is the only input that will read an AIM beacon
33. Digital in 1 Digital input 1. This is the only input that will support an RPM sensor
34. Aux 1 Low side output. Maximum load 2A
35. Aux 2 Low side output. Maximum load 2A
