the Unit field.
Custom unit This field is used for entering a user-defined measurement unit. To use it,
select User in the Unit field.
Text Defines the text displayed below the Value parameter.
Use icon This parameter allows you to display an icon instead of text.
Icon texture Allows you to select an icon from the texture menu. You can add a
custom icon (more information about managing textures is provided
further in the manual)
Icon scale The icon size is automatically adapted to the indicator size. You may
change its size using the Icon Scale parameter.
Alarm channel A channel / function to change the indicator colour when its value differs
from 0. The alarm colour is defined in the Alarm Color field.
Radius The indicator diameter in pixels.
Line width The indicator line width in pixels. Decimal values are possible.
Color The indicator line colour
Value color The displayed value colour
Text color The text or icon colour
Unit color The measurement unit colour
Alarm color The colour to which the indicator and the displayed value will change if
the value of the variable used in Alarm channel differs from 0.
Background color The indicator background line colour
Value font The size of the font used for displaying values
Text font The size of the font used for displaying text
Unit font The size of the font used for displaying measurement units
Legend font The size of the legend font
