Epson TM-U950 Technical Manual

3-16 Handling and Maintenance Rev. A
35 Six shafts of frame-main assembly G-36
36 Roller-sub slip paper feed assembly mounting two U-cut notches of frame-main assembly G-15
37 Gear of roller-slip paper feed assembly G-36
38 Paper feed deceleration gear G-36
39 Receipt transmission gear G-36
40 Notch of J/S changeover gear G-36
41 Paper feed deceleration gear G-36
42 Bigger wheel gear of gear-journal transmission G-36
Table 3-3. Lubrication Points for Printer Mechanism Unit (for printers with an MICR reader)
No. Lubrication Point (See lubrication point diagrams at end of Chapter 6 (Appendix) Type
1 Roller-sub paper feed assembly mounting U-cut notches (four) of paper guide-upper G-36
2 Roller mounting portions of sub paper hold roller G-36
3 Shaft of paper guide-lower G-15
4 Lever-stamp sliding portions (three) of paper guide-lower G-36
5 Lever-stamp drive hooking portion of lever-stamp G-15
6 Iron core notch G-15
7 Shaft of cutter motor mount plate sub assembly G-36
8 Bigger wheel of deceleration gear A G-36
9 Two holes of each paper hold roller G-36
10 Two shafts of cutter frame sub assembly G-36
11 Center wheel of cutter drive shaft sub assembly G-36
12 Both wheel of deceleration gear B G-36
13 Bigger wheel of deceleration gear A G-36
14 Cutter slider contact portion of frame-cutter blade receiving assembly G-36
15 Circuit pattern on cutter slider assembly G-20
16 Shaft of pulley base-carriage transmission assembly G-36
17 Oil ring O-2
18 Two shafts of frame-carriage assembly G-15
19 Carriage catching surface (above) of frame-carriage assembly (five) G-19
20 Carriage catching whole surface (below) of frame-carriage assembly G-19
21 Five shafts of frame-carriage assembly G-36
22 Wheel of carriage feed pulley G-36
23 Ribbon feed transmission gear G-36
24 Gear-ribbon feed G-36
25 Five points on lever-MICR head holder change G-15
Table 3-2. Lubrication Points for Printer Mechanism Unit (for printers without an MICR reader)
No. Lubrication Point (See lubrication point diagrams at end of Chapter 6 (Appendix) Type
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
