5-30 Disassembly, Assembly, and Adjustments Rev. A
Sub-assembly L-(2)
8. Align the U-shaped groove with dowel and mount the pulley base-carriage transmission
assembly. Provisionally tighten the screw. (Final tightening is in carriage transmission belt
tension adjustment on page 5-56.)
9. Attach the shaft holder-slip feed roller to the lever-guide shaft support.
10.*Pass the roller-slip hold assembly B through the belt-MICR feed, and fit the belt onto
the gear.
11. Pass the roller-slip hold assembly B over the shaft holder-slip feed roller attached to the
lever-guide shaft support-JB, and attach it using the RE fittings.
12. Align the dowel and hole of the assembled lever-guide shaft support-JB, and fit it onto
the frame-carriage assembly.
13. Pass the shaft-carriage guide over the carriage-head assembly, and with the side first,
insert it into the hole in the frame-carriage assembly, and tighten the screw marked in the
illustration.
✔
Checkpoint
When attaching the assembly, the spring-carriage holder should be under the frame, with
the part marked cutting into the frame.
14. Fit the belt of the carriage-head assembly onto the pulley-carriage transmission and carriage
feed pulley.
15. Fit the belt-slip paper feed onto the roller-slip hold assembly B.
16. Attach the lever-guide shaft support-RB to the shaft holder-slip feed roller.
17. Pass the roller-slip hold assembly B over the shaft holder - slip feed roller attached to the
lever-guide shaft support-RB, and set it on the frame-carriage assembly.
18. Secure the lever-guide shaft support-RB to the carriage guide with screws.
19. Secure the roller-slip hold assembly B with the RE fittings.
✔
Checkpoints
Make sure the belt-MICR feed is meshed with the gears of the roller-slip hold assembly B
and roller-MICR head holder.
Attach the support lever springs J (long) and R (short).
