Operating of the Machine
4-60 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Teach
Package
Dispensing
In case of using a dispenser, choose the desired dispensing pattern (see online help for detailed
information).
Teach
Package
Save as...
Type in the name of the new package and click Save.
Create new Fiducial
Teach
Fiducial
New
Choose one of the available fiducial template
Create
Define the variou
s parameters
Find best light settings
The machine is searching the best light settings
for the new fiducial. The found settings are
compared with existing light profiles. The
machine list the existing light profiles which is
close to the found settings.
Choose the found
profile or store a new one with the exact settings
found.
Teach
Fiducial
Save as...
Type in the name of the new fiducial and click
Save
.
