Human Machine Interface HMI
Paraquda Startup & Safety © Essemtec AG
3-3
0000003/11 / November 4, 2014
3.1.2 Signal Tower
Signal Lamps
The user programmable signal lamps (red,
yellow, green, also blue and white possible) of
the signal unit provide visual status indication of
the machine. Furthermore the color information
is widened by the states On, Of
f or Blinking.
Additionally a signal unit with a buzzer can be
installed and programmed according to the
state (see online help).
3.1.3 Monitor
Overview
One color LCD touch screen monitor with
a
resolution of 1440 x 900 pixels is mounted at the
signal tower on the right side of the machine.
Depending on the serial number of the machine,
different monitor types are possible (monitor a,
monitor b etc.)
