Operating of the Machine
4-20 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Thread the cover tape as shown on picture.
Close the downholder.
Wind up the cover tape on the bobbin.
Put together the magnetic held cover tape
spool.
Look after the correct placement of the face
gear, it must be on gear side of the feed
mechanism (see next picture).
Place the cover tape spool on the feed
mechanism.
