7 Basic Manual Control 113
Setting Parameters with the Keypad
When the CIA is placed in parameter mode, all parameters of selected channels may be given
numeric values through the keypad. Linear devices can be provided instructions from 0-100, pan
and tilt are controlled from -270 to 270 and -135 to 135 respectively. Saturation controls are
represented from 0 to 360 and Hue controls are represented from 0 to 100. CMY and RGB are
represented from 0-255.
When no channels are selected, the CIA shows all of the parameters that are available in the
lighting system. When channels are selected, the CIA condenses to show only the parameters that
are appropriate to the selection set. If channels are selected that have different device types, such
as spot and wash lights, the CIA will show all of the available parameters. Parameters that are not
available to all channels are greyed out.
The following examples illustrate how to set parameter values with the keypad:
• [5] {Iris} [5] {Zoom} [6] [5] {Edge} [5] [Enter] - sets channel 5 to an iris value of 50%, a zoom
value of 65%, and an edge value of 50%.
Note:
Pressing down on an encoder will place the associated parameter onto the
command line for numeric entry.
