Step 6: To select a device interface (optional), press {Interface}.
• This displays up to six buttons labeled {ACN}, {EDMX}, {ArtNet}, {Avab UDP},
{DMX}, and {Default}. Select an interface for the selected device. Once your
selection is made, the command line will populate with the selected interfaces
and terminate. If left blank, the {Default} is used as selected in the {Network}
section of the ECU.
Step 7: Select the {Attributes} softkey to set detailed moving light attributes.
• The following buttons may be available on this page: {Invert Pan} and {Invert
Tilt}, {Swap}, {Scroller}, {Gobo Wheel}, {Color Wheel}, {Preheat},
{Proportion}, and {Curve}.
• If your moving light includes parameters such as a color scroller or gobo
wheel and you have custom gels or non-standard patterns installed, use the
Scroller/Wheel Picker and the Editor to modify the device patched (See
Using the Scroller/Wheel Picker and Editor, page 79). The more specific your
patch data (including accurate colors and patterns) the more detailed
programming and operating will be.
Step 8: Select the {Database} softkey to specify notes and keyword text related to your
selected channel for reference and future queries.
• Pressing the {Notes} and/or a {Text} button opens the virtual keyboard on the
CIA. Pressing [Enter] returns the CIA to the database page.
Patching a Compound Channel
A compound channel consists of any channel that controls more than one device. It can consist of
mutliple dimmers patched to the same channel or accessories patched to a channel (such as a
fixture with a color scroller, a fixture with a gobo wheel, and so on). This will appear as a part. By
default, Eos will add a part if you are trying to patch to a channel that has already been assigned an
address.
To patch a compound channel in channel format:
• [9] [At] [5] [4] [0]
Assuming that channel 9 is already patched to an address, this will create a part 2 and
address it at output 540. Or you can use:
• [8] [Part] [2] [At] [5] [1] [3]
This will create a part 2 for channel 8 and address it at output 513. If you wish to patch by
address while in the channel view, press:
• {Address} [5] [1] [3] [At] [8] [Enter]
This will perform the same action as the previous example, assuming channel 8 was
previously patched to an address.
To patch a compound channel in address format:
• [5] [1] [3] [At] [8] [Enter]
This will perform the same action as the previous example, assuming channel 8 was
previously patched to an address.
CAUTION:
It is recommended that you do not patch more than one multiple-parameter device
(such as moving lights) to the same channel.
Note:
If at any point you try to patch an address that is already in use, Eos will post an
advisory to indicate this, preventing you from duplicating addresses in your patch.
