ETC EOS - Chapter 5 Patch

5 Patch 65
Chapter 5
Patch
The Patch is where patching data is stored and can be viewed using the patch display. Once a
channel is patched to an output, and the output is connected to a device (for example a dimmer,
moving light, or accessory), the channel will then control that device.
This chapter contains the following sections:
• Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
• Create and Edit Patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
• Patching a Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
• Patching Moving Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
• Display Pages in Patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
• Using the Scroller/Wheel Picker and Editor . . . . . . . . . . . . .79
• Calibrating a Scroller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
• Changing the Patch View . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
• Deleting Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
• Clearing the Patch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
• Fixture Creator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
• Update Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
