Fader Control Buttons
Fader control buttons are provided for easy local control of fader behavior. Control buttons include:
Manual Override, Spread, Release, Off, Assert, Go to Cue 0, Stop Effect, Freeze, Filter and Timing
Disable. Individual faders are provided with immediate controls including: Go, Stop and Back (for
playbacks), bump and solo (when submasters), or blackout and blackout enable when configured
as grandmasters.
Rate and Fader Page
Rate and Fader Page buttons are provided for use with the faders.
Load
Load buttons are located above the faders at the bottom of LCD 1 and are used to load the
specified cue or submaster to the associated fader or place special conditions on that fader.
Control Keypad
The control keypad area is divided into four general sections including record
targets, numeric keypad, modifiers, and special function controls.
Level Wheel
Proportionally adjusts intensity for selected channels. It also provides scrolling/
zoom functions in various modes.
Navigation Keypad
Used for quick access to the Live and Blind displays, tab selection, location, paging and navigation
within displays.
Parameter / Category Buttons
Parameter buttons are used in conjunction with the Central Information Area (CIA). When certain
functions need to be accessed, a group of related parameters will populate in the parameter
category display.
IEEE Ethernet 802.3af Ethernet Ports
Ethernet ports (including Power-Over-Ethernet) for connection to a network switch, network
gateways, and accessory devices.
Littlites
®
You may connect Littlites to the back of your Eos console.
Cleaning Eos
Should the exterior of your Eos require cleaning, you may gently wipe it with a dampened (not
dripping), non-abrasive paper towel or soft cloth.
If this does not clean the console sufficiently, you may apply some window cleaner (containing
ammonia is fine) to the cloth and repeat the process until clean.
