17 Multipart Cues 229

Chapter 17

Multipart Cues

Cues can be divided into up to 20 parts. This chapter describes the methods used to create and edit

multipart cues.

This chapter contains the following sections:

• Record a Multipart Cue in Live . . . . . . . . . . . . . . . . . . . . . . .230

• Storing a Multipart Cue in Blind . . . . . . . . . . . . . . . . . . . . . .233
