210 Eos Operations Manual
Introduction to Playback
Eos offers one master fader pair and ten motorized faders with 30 pages of control. You can define,
on a page by page and fader by fader basis, how each of the ten faders will function: as playbacks
for cues, submasters (additive, inhibitive, or effect), or as grandmasters. There is no default setting
for faders, which allows you the freedom to define each faders’ function in Setup (Setup, page 91)
or you can configure them while programming, as the contents of those targets are stored.
You can page the ten motorized faders using the [Fader Page] button alone, combined with the
numeric keypad, or with the wheel directly below the [Fader Page] button. As pages are changed,
the faders will reset to the last position they were in on the associated page. Also, each individual
fader is provided with a [Load], [Go], and a [Stop/Back] button for operation and playback. These
buttons behave differently when the fader is a submaster or grandmaster. A playback display is
located directly above the faders and provides information about each fader including the fader
designation (S = submaster with the designation of the submaster number, L = playback with
designation of the cue list and cue number that is loaded, or GM = grandmaster).
The master playback fader pair is located to the right of the ten fader array, near the control keypad.
The master is a split cross-fader pair. You cannot page the master fader as it is permanently paired
and always available for use. The two buttons beneath the master fader pair are [Go] and [Stop/
Back]. The [Load] button and playback display are located just above the potentiometers.
Playback Controls
.
Load buttons
Rate / Fader
page controls
Fader
Control
buttons
Motorized
playback
faders
Master
Fader
Pair
